Browsing by Author "Moran, Luis"

Now showing 1 - 4 of 4
  • Thumbnail Image
    Item
    A series active power filter scheme for current harmonic compensation
    (IEEE, 2008) Figueroa, Diego; Moran, Luis; Ruminot, Pedro; Dixon, Juan
    A series active power filter to eliminate current harmonic components and compensate reactive power is presented and analyzed. The proposed active compensation technique is based in a series active filter composed by two single-phase inverters sharing the same DC bus, and is suitable for current harmonics and reactive power compensation generated by static converters. The proposed approach allows for low cost, simplicity and part count reduction in comparison with previous compensation solutions (passive and active). The paper analyzes the proposed series active power filter in terms of principles of operation, power circuit topology, control design and implementation. Experimental results obtained in a laboratory DSP based controlled prototype confirm the viability of the proposed compensation technique.
  • Thumbnail Image
    Item
    High power machine drive, based on three-stage connection of "H" converters, and active front end rectifiers
    (IEEE, 2003) Dixon Rojas, Juan; Breton, Alberto A.; Rios, Felipe E.; Moran, Luis
    A three-stage inverter using "H" converters is being analyzed for high power machine drive applications. The great advantage of this kind of converter is the minimum harmonic distortion obtained at the machine side. The drawbacks are the isolated power supplies required for each one of the three stages of the multiconverter. In this paper this problem has been overcome in two ways: 1) by using independent windings for each phase of the motor, or 2) by using independent input transformers. Special configurations and combinations of passive rectifiers and active front end rectifiers for one of the stages of the drive are used to eliminate all input harmonics. The topology can also keep unity power factor at the input terminals. Simulation results are shown and some experiments with small four-stage prototypes are displayed. The control of this multi-converter is being implemented using DSP controllers, which give flexibility to the system.
  • Thumbnail Image
    Item
    Passive Filters for High Power Cycloconverter Grinding Mill Drives
    (IEEE, 2009) Aravena, Pablo; Vallebuona, Giovanni; Moran, Luis; Dixon Rojas, Juan, 1948-; Godoy, Orlando
    This paper presents a design method for passive filters used to compensate power factor and current harmonics generated by high power cycloconverter drives. The paper includes the analysis of different passive filter topologies effectiveness (band-pass, high-pass and C type), a procedure to calculate filter parameters, tuning frequency selection, and reactive power distribution. The passive filters are designed to compensate high power grinding mill drives energized from cycloconverters. Simulated results based on a real grinding mill plant prove the effectiveness of the proposed method.
  • No Thumbnail Available
    Item
    Static Var Compensator and Active Power Filter With Power Injection Capability, Using 27-Level Inverters and Photovoltaic Cells
    (IEEE, 2009) Flores Lara, Patricio Armando; Dixon Rojas, Juan, 1948-; Ortuzar, Micah; Carmi, Rodrigo; Barriuso, Pablo; Moran, Luis
    An active power filter and static var compensator with active power generation capability has been implemented using a 27-level inverter. Each phase of this inverter is composed of three ldquoHrdquo bridges, all of them connected to the same dc link and their outputs connected through output transformers scaled in the power of three. The filter can compensate load currents with a high harmonic content and a low power factor, resulting in sinusoidal currents from the source. To take advantage of this compensator, the dc link, instead of a capacitor, uses a battery pack, which is charged from a photovoltaic array connected to the batteries through a maximum power point tracker. This combined topology make it possible to produce active power and even to feed the loads during prolonged voltage outages. Simulation results for this application are shown, and some experiments with a 3-kVA device are displayed.
