Browsing by Author "Gudmundsson, Jon E."

Now showing 1 - 3 of 3
  • Thumbnail Image
    Item
    Freeform three-mirror anastigmatic large-aperture telescope and receiver optics for CMB-S4
    (2024) Gallardo, Patricio A.; Puddu, Roberto; Harrington, Kathleen; Benson, Bradford; Carlstrom, John E.; Dicker, Simon R.; Emerson, Nick; Gudmundsson, Jon E.; Limon, Michele; Mcmahon, Jeff; Nagy, Johanna M.; Natoli, Tyler; Niemack, Michael D.; Padin, Stephen; Ruhl, John; Simon, Sara M.
    CMB-S4, the next-generation ground-based cosmic microwave background (CMB) observatory, will provide detailed maps of the CMB at millimeter wavelengths to dramatically advance our understanding of the origin and evolution of the universe. CMB-S4 will deploy large- and small-aperture telescopes with hundreds of thousands of detectors to observe the CMB at arcminute and degree resolutions at millimeter wavelengths. Inflationary science benefits from a deep delensing survey at arcminute resolutions capable of observing a large field of view at millimeter wavelengths. This kind of survey acts as a complement to a degree angular resolution survey. The delensing survey requires a nearly uniform distribution of cameras per frequency band across the focal plane. We present a large-throughput (9.4 degrees field of view), large-aperture (5-m diameter) freeform three-mirror anastigmatic telescope and an array of 85 cameras for CMB observations at arcminute resolutions, which meets the needs of the delensing survey of CMB-S4. A detailed prescription of this three-mirror telescope and cameras is provided, with a series of numerical calculations that indicates expected optical performance and mechanical tolerance.
  • Thumbnail Image
    Item
    The Simons Observatory: Beam Characterization for the Small Aperture Telescopes
    (2024) Dachlythra, Nadia; Duivenvoorden, Adriaan J.; Gudmundsson, Jon E.; Hasselfield, Matthew; Coppi, Gabriele; Adler, Alexandre E.; Alonso, David; Azzoni, Susanna; Chesmore, Grace E.; Fabbian, Giulio; Ganga, Ken; Gerras, Remington G.; Jaffe, Andrew H.; Johnson, Bradley R.; Keating, Brian; Keskitalo, Reijo; Kisner, Theodore S.; Krachmalnicoff, Nicoletta; Lungu, Marius; Matsuda, Frederick; Naess, Sigurd; Page, Lyman; Puddu, Roberto; Puglisi, Giuseppe; Simon, Sara M.; Teply, Grant; Tsan, Tran; Wollack, Edward J.; Wolz, Kevin; Xu, Zhilei
    We use time-domain simulations of Jupiter observations to test and develop a beam reconstruction pipeline for the Simons Observatory Small Aperture Telescopes. The method relies on a mapmaker that estimates and subtracts correlated atmospheric noise and a beam fitting code designed to compensate for the bias caused by the mapmaker. We test our reconstruction performance for four different frequency bands against various algorithmic parameters, atmospheric conditions, and input beams. We additionally show the reconstruction quality as a function of the number of available observations and investigate how different calibration strategies affect the beam uncertainty. For all of the cases considered, we find good agreement between the fitted results and the input beam model within an similar to 1.5% error for a multipole range l = 30-700 and an similar to 0.5% error for a multipole range l = 50-200. We conclude by using a harmonic-domain component separation algorithm to verify that the beam reconstruction errors and biases observed in our analysis do not significantly bias the Simons Observatory r-measurement
  • No Thumbnail Available
    Item
    The Simons Observatory: modeling optical systematics in the Large Aperture Telescope
    (2021) Gudmundsson, Jon E.; Gallardo, Patricio A.; Puddu, Roberto; Dicker, Simon R.; Adler, Alexandre E.; Ali, Aamir M.; Bazarko, Andrew; Chesmore, Grace E.; Coppi, Gabriele; Cothard, Nicholas F.; Dachlythra, Nadia; Devlin, Mark; Dunner, Rolando; Fabbian, Giulio; Galitzki, Nicholas; Golec, Joseph E.; Ho, Shuay-Pwu Patty; Hargrave, Peter C.; Kofman, Anna M.; Lee, Adrian T.; Limon, Michele; Matsuda, Frederick T.; Mauskopf, Philip D.; Moodley, Kavilan; Nati, Federico; Niemack, Michael D.; Orlowski-Scherer, John; Page, Lyman A.; Partridge, Bruce; Puglisi, Giuseppe; Reichardt, Christian L.; Sierra, Carlos E.; Simon, Sara M.; Teply, Grant P.; Tucker, Carole; Wollack, Edward J.; Xu, Zhilei; Zhu, Ningfeng
    We present geometrical and physical optics simulation results for the Simons Observatory Large Aperture Telescope. This work was developed as part of the general design process for the telescope, allowing us to evaluate the impact of various design choices on performance metrics and potential systematic effects. The primary goal of the simulations was to evaluate the final design of the reflectors and the cold optics that are now being built. We describe nonsequential ray tracing used to inform the design of the cold optics, including absorbers internal to each optics tube. We discuss ray tracing simulations of the telescope structure that allow us to determine geometries that minimize detector loading and mitigate spurious near-field effects that have not been resolved by the internal baffling. We also describe physical optics simulations, performed over a range of frequencies and field locations, that produce estimates of monochromatic far-field beam patterns, which in turn are used to gauge general optical performance. Finally, we describe simulations that shed light on beam sidelobes from panel gap diffraction. (C) 2021 Optical Society of America
